The RAB1 Embedded processors are based on the powerful Rabbit 3000 processor and the
Rabbit RMC3000 series Core modules. They allow expansion with MicroBus
peripherals.The RAB1-3200 provides 10/100 BaseT Ethernet.
| RAB1 Version |
Flash PROM |
RAM |
Ethernet |
| RAB1-3100 |
512KB |
256KB |
No |
| RAB1-3110 |
256KB |
128KB |
No |
| RAB1-3200 |
512KB |
256KB |
Yes |
| RAB1-U |
User Supplied Rabbit Core Module |
This is a drawing of a RAB1 processor installed in a MicroBus system with one other
MicroBus I.O board. Note the Rabbit RCM module mounted to the RAB1 carrier.
RAB1 Features
 | Large Program and Data Memory up to 1MB total |
| 4 Serial Ports |
| 40 Parallel I/O lines |
| LCD Alphanumeric and Keypad Interface |
| Optional 10/100 Ethernet |
| Quadrature encoder Inputs |
| Three timer / counters |
| Analog Input: 8 Channels, 8/12(?) bit resolution |
| MicroBus Expansion |
Firmware Development
| Low cost powerful development using Rabbit Dynamic C IDE |
| All peripherals including MicroBus modules supported with C libraries |
| Royalty-free TCPIP Libraries for Ethernet versions |
Data Sheets and Manuals
Pricing
| RAB1 Version |
Qty. 1 |
Qty. 10 |
Qty. 100 |
| RAB1-3100 |
$99 |
$89 |
$79 |
| RAB1-3110 |
$129 |
$119 |
$109 |
| RAB1-3200 |
$149 |
$139 |
$129 |
| RAB1-U |
$49 |
$45 |
$39 |
|
